Hebezeug Program
I-hoist
| Model No | Capacity | Proof Load | I-Beam Width | Min. Radius Curve | Net Weight | Dimensions | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| ( kg ) | ( kg ) | ( mm ) | ( m ) | ( kg ) | A | B | C | D | E | |
| FPT-1 | 1000 | 1500 | 50-152 | 1,0 | 12,8 | 296 | 257 | 181 | 30 | 23,5 |
| FPT-2 | 2000 | 3000 | 64-203 | 1,1 | 18,8 | 313 | 300 | 214,5 | 36 | 23,5 |
| FPT-3 | 3000 | 4500 | 88-203 | 1,3 | 33,7 | 334 | 340 | 252 | 45 | 32,5 |
| FPT-5 | 5000 | 7500 | 114-203 | 1,4 | 50,7 | 363 | 380 | 290 | 60 | 28 |
